Auto Servo Leading edge Feeder, Prefeeder of Printer, Die cutter
To get more details about our Carton box Smart equipments, pls visit here
Description
• Model: NCFYJC-2200 Automatic Servo Feeding Machine
• Performance: This machine adopts servo control and automatic paper feeding. It is used for automatic paper feeding of various types of printers, die-cutting machines,etc. It has high production efficiency, accurate positioning, simple operation, and safety & reliability.
• Configuration instructions:
* Adopt Schneider servo controller to control servo motor to feed paper accurately;
* Feeding roller choose special Sun Wheel to realize continuous feeding;
* Front baffle is easy to adjust, and have self-locking function; Right side baffle adjusts position automatically, Left side baffle adjusts electrically.
* The paper feed table is equipped with multiple sets of bearing rollers, which reduces the friction between the paperboard and the tabletop.
* Multiple sets of bellow adjust the damper independently, which can be adjusted according to the width of the cardboard by hand.
* Be equipped with one set of Taiwan brand fan (5.5kw), with silencer and PU polyurethane wire duct (4 meters).
Tech parameter:
|
1 |
Max. feeding width |
2200mm |
|
2 |
Min feeding width |
500mm |
|
3 |
Design work speed |
180m/min |
|
4 |
Paper range |
E. B, C, A, AB corrugated cardboard (1.5-9mm) |
|
5 |
Machine Size |
2680mm × 2180mm × 1510mm (long × wide × High) |
|
6 |
Power |
10KW |
|
7 |
Power supply |
380v 50HZ |
|
8 |
Weight |
2000KG |
Main material configuration list
|
Item |
Description |
Quantity(pcs/set) |
|
1 |
Precision gearbox ; Speed ratio19:25 |
1 |
|
2 |
Servo motor 3kw |
1 |
|
3 |
Servo drive |
1 |
|
4 |
Right side baffle position automatically |
1 |
|
5 |
Left side baffle adjusts automatically |
1 |
|
6 |
Back baffle adjusts electrically. |
1 |
|
7 |
Front baffle adjusts electrically. |
1 |
|
8 |
150-250mm；Special chosen sun wheel feeding roller; Single rubber feeding paper arc length 150-250mm; |
4 |
|
9 |
Sliding bearing roller table |
1 |
|
10 |
Paper roller; 304 stainless steel |
2 |
|
11 |
Feeding fan; 4 meter fan tube |
1 |
|
12 |
Silencer |
1 |
|
13 |
Operation box |
1 |
|
14 |
Touch screen; MCGS |
1 |
